Procedures for various types of installations of the Unisoft Pronto software. Also troubleshooting, user manuals and menu customization.


There are several types of software installations for the Unisoft software outlined below and click the one you wish:

       1) Fresh install to a new computer that has not had the Unisoft software previously installed

       2) Update a computer that has had the Unisoft Software previously installed

       3) Install the Unisoft license file to allow additional feature privileges.


In addition the menus displayed can be customized and this is useful when the software is used in various departments on your production floor.




INSTALLATION: Fresh install - Installing to a computer that has not had the Unisoft Pronto Software previously installed

The software installation setup below will install the Unisoft Pronto software on your hard drive (c:\program files (x86)\unisoft by default, or c:\program files\unisoft).

You may install the Unisoft software on additional computers if properly licensed to do so. By installing the Unisoft software you agree to the terms of the license. Licensing may be confirmed periodically. Software features and functions are subject to change without notice. Any misuse may void the license. By installing or otherwise using the Unisoft software you agree to be bound by the terms of the current Unisoft End-User License Agreement (EULA).

Click or cut and paste into your browser the following link:
https://www.unisoft-cim.com/download/requests/view-markup/view.zip

After the download is complete unzip VIEW.ZIP then double-click on VIEW.EXE and follow the instructions on the screen to install the software. Please accept the default path on installation, it can be changed later.

The installation is complete for the viewer software. If you wish please contact us for training.


Troubleshooting Pronto software: If the Unisoft Pronto software does not run correctly after installation it is usually a folder/file permissions issue. To see if it is a permissions issue try installing Unisoft software to a new directory that you the installer creates on the C: root drive, for example   c:\unisoft-test   and if the software runs correctly there it is most likely a permissions issue which you or your IT department can correct. Contact Unisoft for help.




INSTALLATION: Update a computer that has had the Unisoft Software previously installed

Unisoft subscription customers automatically have a current Unisoft software license contract and can update their software to the latest version at anytime using the procedure below. If your license contract has expired do not install this release and contact Unisoft to find out how to enable this new release.


Follow the procedure below to install the Unisoft Pronto software update on computers with the software already installed.

By installing the Unisoft software you agree to the terms of the license. Licensing maybe confirmed periodically. Software features and functions are subject to change without notice. Any misuse may void the license. By installing or otherwise using the Unisoft software you agree to be bound by the terms of the current Unisoft End-User License Agreement (EULA).

To install the Unisoft Pronto software update click or cut and paste into your browser the following link: https://www.unisoft-cim.com/download/update-view.zip

After the download is complete unzip the file  UPDATE-VIEW.ZIP  to your desktop. Next double-click the file  UPDATE-VIEW.EXE  on your desktop and follow the instructions on the screen to install the software. Please install to the directory where the Unisoft software was previously installed by default     c:\program files (x86)\unisoft   or    c:\program files\unisoft) .

You may delete the file  UPDATE-VIEW.EXE  on your desktop.

The installation is complete!  If you wish please contact us for training.



Troubleshooting:
If the Unisoft software does not run correctly after installation it is usually a folder / file permissions issue. To see if it is a permissions issue try installing Unisoft software to a new directory that you the installer creates on the C: drive root, for example  c:\unisoft-test  and if the software runs correctly there it is most likely a permissions issue which you or your IT department can correct. Contact Unisoft for help.

For more information on file / folder permission issues click here

For additional installation troubleshooting information click here.





INSTALLATION: License installation

For certain PC's on your production floor you may wish to have only the limited functionality of the Unisoft viewer software installed above. For these computers please skip the license installation procedure in this section.

You may install the license on additional computers if properly licensed to do so. By installing the license you will be giving additional functionality to the Unisoft viewer software. By installing you agree to the terms of the license. Licensing maybe confirmed periodically. Software features and functions are subject to change without notice. Any misuse may void the license. By installing or otherwise using the Unisoft software you agree to be bound by the terms of the current Unisoft End-User License Agreement (EULA).

Please unzip to your desktop the license file received from Unisoft. At this point you should see the file  MARKUP.LIC  on your desktop. Next copy that file into the Unisoft directory by default     c:\program files (x86)\unisoft   or    c:\program files\unisoft) .

You may delete the file  UPDATE-VIEW.EXE  on your desktop.

You may delete the file   MARKUP.LIC  on your desktop.

The license installation is complete and the licensed software is now active.


Troubleshooting: PROBLEM NEW LICENSE NOT BEING SEEN: When you first start the software a splash screen appears and with the license properly installed in that window you will see in the first sentence of the first paragraph will say "this product is licensed to >> " and after that it will indicate your company name and other licensing information. If you see this then the license is installed properly.

If after installing the new license using the procedure above provided you start the Unisoft software and it appears that the new license is not being seen you can either contact Unisoft directly and we will go online and help you with the issue or you can try the following.

  1. From the hard drive you installed the Unisoft software too search from the root directory for the file MARKUP.LIC .
  2. Your search may have come up and found a MARKUP.LIC file in for example the directory c:\program file (x86)\unisoft and possibly also in a path with the name VirtualStore in it. Please delete any copies of MARKUP.LIC your search came up with.*
  3. Unzip the Unisoft license file you received to your desktop. At this point you should see the file MARKUP.LIC on your desktop. Next copy that file into the Unisoft directory which is by default
    c:\program files (x86)\unisoft OR c:\program files\unisoft . You may delete the file MARKUP.LIC on your desktop.
  4. Start the Unisoft software and see if the problem has been resolved. If it has not then please contact Unisoft directly and we can go online with you and fix it.

*LICENSE NOT BEING SEEN CORRECTLY - VIRTUALSTORE DIRECTORY ISSUE:

When the Unisoft software is not seeing the license file correctly then the problem can be the following. Sometimes the problem is that when a valid license file, a markup.lic file, is manually copied to replace the existing markup.lic file in the default directory   c:\program files(x86)\unisoft   and the Unisoft software when started does not detect the new license file is that the Microsoft operating system is redirecting the Unisoft software to use another older copied of the Unisoft license file.

The Microsoft Windows OS for some versions will sometimes create a VirtualStore directory and in that directory there will be subfolders of directories such as   \Program Files(x86),   \Windows, etc. Then when files are manually or otherwise copied to the actual directory such as   c:\Program Files(x86)   and   c:\Windows   virtual copies of these files are also copied to the   VirtualStore   directory. Then when the software application program is started the Windows OS redirects the software application to use the file(s) in the   VirtualStore   directory instead of where it was originally copied to.  This   VirtualStore   directory issue is not something that Unisoft can control.

So the problem can usually be remedied by either editting directly, removing or overwriting the   VirtualStore   directory copy of the file(s) in question.

If you do have a   VirtualStore   directory it will usually be under your USER directory and an example follows   c:\user\xxxx\appdata\local\virtualstore\   where   xxxx   is your Windows user log-in name. The   markup.lic   file maybe found at   c:\user\xxxx\appdata\local\virtualstore\program files(x86)\unisoft.


For additional installation troubleshooting information click here.





TRAINING & HELP

Training is available virtually anytime online. Also the software has HELP for most menu items by hovering over the menu item for a second then click any of the videos, manual or website links to learn about the software.




USER MANUALS

User manuals for the Unisoft Pronto series software in Microsoft Word are installed on the computer in the directory: c:\program files\unisoft by default, or c:\program files(x86)\unisoft. These same manuals are also available online. The online manuals can be translated into approx. 100 languages by clicking "select Language" in the upper right of the webpage.

PCB Card

ProntoVIEW-MARKUP manual MS Word:
QUICK-START_VIEW-MARKUP.doc
ProntoVIEW-MARKUP manual online:
ProntoGERBER-CONNECTION manual MS Word:
QUICK-START_GERBER-CONNECTION.doc
ProntoGERBER-CONNECTION manual online:
ProntoPLACE manual MS Word:
QUICK-START_PRONTOPLACE.doc
ProntoPLACE manual online:
ProntoAOI manual MS Word:
QUICK-START_PRONTOAOI.doc
ProntoAOI manual online:
ProntoTEST-FIXTURE manual MS Word:
QUICK-START_TEST-FIXTURE.doc
ProntoTEST-FIXTURE manual online:
ProntoSELECTIVE-SOLDERING manual MS Word:
QUICK-START_selectIVE-SOLDERING.doc
ProntoSELECTIVE-SOLDERING manual online:


Customize the Menus and Splash Page

Customize your menus and splash page. You can customize the menus displayed and this is useful when the software is used in various departments on your production floor. For example, for personnel performing PC Board inspection with the included Unisoft PCB assembly ( PCBA ) viewer software you can simplify its use by removing the menus that are not necessary in that department. You can also add custom Splash Page text that will be displayed when the software is first started such as "UNISOFT VIEWER FOR USE IN THE INSPECTION DEPARTMENT".

Before:

After:


For more information and how to use this feature go to   https://www.unisoft-cim.com/view-markup_menus-splash-page_customize-menus-and-splash-page.html .
